Man-machine interface considerations using CBTC GOA2 systems

  • Global
  • automation
  • Staff
Metro automation

What to consider when modernising operations

Metro automation means a shift from conventional signalling systems.

When modernising operations using Communication Based Train Control (CBTC) technology in Grade of Automation 2 (GOA2), there are some areas of change that the drivers and/or the operators must face. Those changes might be directly induced by the operational improvements offered by the new system, but can also be a consequence of the technology used.

This paper intends to collect measures and options that have been taken by public transport operators across eight different countries to cope with those changes.

Contents:

  • Introduction
    • Purpose of the study
    • Methodology
    • Abbreviations
    • Survey contributors
    • Glossary
  • Questionnaire results
    • Part 1 – Use of CBTC technology
    • Part 2 – Main functions of the CBTC
    • Part 3 – Cab-signal and linesight signals cancellation
    • Part 4 – Speed control curves
    • Part 5 – OCC considerations
    • Part 6 – Other
      • Specific training tools for CBTC operations
      • Signal aspect considerations
      • Other MMI considerations
  • Conclusions
  • Recommendations
  • Appendix: Questionnaire

The report is based on the contribution of the following operators:

  • TMB

    Barcelona, Spain

  • STIB

    Brussels, Belgium

  • VGF

    Frankfurt, Germany

  • TfL

    London, United Kingdom

  • Metro de Madrid

    Madrid, Spain

  • RTM

    Marseille, France

  • ATM

    Milan, Italy

  • STM

    Montréal, Canada

  • RATP

    Paris, France
